IllumiFlex Pixel LED Strip (60 LED/M)

High Quality LED Strips that are Ideal for Commercial or Residential Use

IllumiFlex LED strips are extremely versatile, and deliver even dispersion with high-brightness!

  • Warm White (3000K CCT)
  • UL Listed
  • 12V DC
  • High quality flexible circuit strips distribute current more effectively
      than common LED strips to minimize voltage drop.
  • Extremely Versatile Design
  • 12V DC
  • Eco Friendly with Low Power Consumption
  • Easily connects with IllumiSnap™ harnesses to the IllumiSci®
      Modular Family of Products
  • Mounts easily with high quality adhesive
  • Designed to work with a Class 2 power supply
  • Dimmable

Model Versions

MIT-IF-60/M-5050-RGBW

HIGH QUALITY ADDRESSABLE PIXEL LED STRIPS

Our IllumiFlex® Addressable Pixel LED Strips (a.k.a. LED Tape) are designed and manufactured to work well for commercial applications where light quality and robustness are important. IllumiFlex® Flexible LED strips offer a simple, high quality and robust solution to create dramatic, multi-color LED effects with individually addressable LED’s. Use IllumISci devices for control, or use your desired control front-end.

For smaller array applications, use the IllumiSci® and SPI Converters (decoder) make your pixel array simple and easily controllable. As with all of our products, we focus upon robustness of design and longevity so that our products perform in commercial environments.

  • Simple to configure
  • Offered in 60 LED/M or 30 LED/M
  • WS2812 Protocol
  • Works with multiple type of pixel LED control devices
  • RGBW (Red, Green Blue, White)



Voltage

5VDC (Min 4.7VDC, Maximum 5.6VDC, not polarity protected)

Power

9 Watts/Meter

Current (per Meter)

1800mA

Pin Allocations

3-Pin JST Male/Female with additional power leads (+5VDC, GND)
GND: White
Signal: Green
+5VDC: Red

Control Protocol

WS2812

Beam Angle

120 Degrees

LED Type

5050

LED SPacing

60 LED/M = 16.7mm

Length (per Reel)

5 Meters

IP Rating (Moisture & Dust Rating)

IP 20 (Dry, interior environments only)

Life Expectancy

50,000 Hours

PCB (Strip or Tape Width)

10mm (0.34”)

Height

2.15mm (0.09”)

LED Pitch (Spacing)

60 LED’s per Meter

Addressable LED Colors

RGBW

Cuttable Segment Length (1 LED)

16.7mm (0.66”)

Warranty

IllumISci® One year Warranty (Limited)

IllumiFlex Addressable Pixel LED Strip can be used with the DMX-SPI Converter Module or other appropriate front-end control systems since it utilizes the WS2812 protocol.

The IllumiSci® Pixel LED Converter Module can be used with a variety of pixel LED strip protocols. See specifications for details.

IllumiSci Product Family Datasheet r1.4.0

IllumiFlex User Manual r1.4
