Control a DMX Universe of Pixel LED’s Easily

DMX-SPI Converters to Make Your Pixel LED Systems Easy to Configure

• Simple to configure
• Designed and manufactured in the United States.
• Supports Multiple Pixel LED chipsets
• Easily select which chipset you want to control. The desired chipset
  to control is selectable by using input switches, and the selected chipset is saved to memory.
• Features a mode that decodes DMX-512 data, then sends out
  the data converted to TTL serial and/or standard SPI.
• Small form factor enclosure
• Has color order or color swap feature that makes non-RGB
  order chipsets accept RGB ordered data.
• Supports full DMX-512 universes with the applicable
  color order settings.
• Supports TTL Serial input at all baud rates, such as control from an
  Arduino or other serial output devices, up to 2048 pixels.
• Baud rate can be selected with the DIP switches.
• Can support WiFi with an ESP8266, XBee, Bluetooth
  or similar product.
• Supports wide voltage ranges, 3.3v to 12 volt support, and supports
  single cell lithium battery voltages.
• Bootloader support that allows you to easily apply any future
  upgrades or bug fixes.

Model Versions

IS-DMX-SPI-R1
